ADG1402BRMZ Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
- Description: IC SWITCH SPST 1OHM RON 8MSOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADG1402BRMZ Specifications:
- MfrPart.: ADG1402BRMZ-REEL7
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: IC SWITCH SPST 1OHM RON 8MSOP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- SwitchCircuit: SPST - NC
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 1
- On-StateResistance(Max): 1.3Ohm
- Channel-to-ChannelMatching(ΔRon): 200mOhm
- Voltage-SupplySingle(V+): 5V ~ 16.5V
- Voltage-SupplyDual(V±): ±4.5V ~ 16.5V
- SwitchTime(TonToff)(Max): 150ns, 150ns
- -3dbBandwidth: 120MHz
- ChargeInjection: -12pC
- ChannelCapacitance(CS(off)CD(off)): 36pF, 41pF
- Current-Leakage(IS(off))(Max): 400pA
- Crosstalk: -
- OperatingTemperature: -40°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
- ADG1402BRMZ Analog Devices (ADI), IC SWITCH SPST 1OHM RON 8MSOP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG1402BRMZ, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
