ADG509AKPZ Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 20-LCC (J-Lead)
- Description: DIFFERENTIAL MULTIPLEXER, 1 FUNC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADG509AKPZ Specifications:
- MfrPart.: ADG509AKPZ-REEL
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: DIFFERENTIAL MULTIPLEXER, 1 FUNC
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Bulk
- Series: -
- PartStatus: Active
- SwitchCircuit: SP4T
- Multiplexer/DemultiplexerCircuit: 4:1
- NumberofCircuits: 2
- On-StateResistance(Max): 450Ohm
- Channel-to-ChannelMatching(ΔRon): 22.5Ohm
- Voltage-SupplySingle(V+): 10.8V ~ 16.5V
- Voltage-SupplyDual(V±): ±10.8V ~ 16.5V
- SwitchTime(TonToff)(Max): 300ns, 300ns
- -3dbBandwidth: -
- ChargeInjection: 4pC
- ChannelCapacitance(CS(off)CD(off)): 5pF, 11pF
- Current-Leakage(IS(off))(Max): 1nA
- Crosstalk: -
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Surface Mount
- Package/Case: 20-LCC (J-Lead)
- ADG509AKPZ Analog Devices (ADI), DIFFERENTIAL MULTIPLEXER, 1 FUNC, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG509AKPZ, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
