ADG5209FBRUZ Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-TSSOP (0.173, 4.40mm Width)
- Description: IC MULTIPLEXER 5CH 16-TSSOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADG5209FBRUZ Specifications:
- MfrPart.: ADG5209FBRUZ
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: IC MULTIPLEXER 5CH 16-TSSOP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Active
- SwitchCircuit: SP4T
- Multiplexer/DemultiplexerCircuit: 4:1
- NumberofCircuits: 2
- On-StateResistance(Max): 160Ohm
- Channel-to-ChannelMatching(ΔRon): 3.5Ohm
- Voltage-SupplySingle(V+): 9V ~ 40V
- Voltage-SupplyDual(V±): ±9V ~ 22V
- SwitchTime(TonToff)(Max): 140ns, 185ns
- -3dbBandwidth: 130MHz
- ChargeInjection: 0.4pC
- ChannelCapacitance(CS(off)CD(off)): 2.8pF, 17pF
- Current-Leakage(IS(off))(Max): 100pA
- Crosstalk: -90dB @ 1MHz
- OperatingTemperature: -40°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-TSSOP (0.173, 4.40mm Width)
- ADG5209FBRUZ Analog Devices (ADI), IC MULTIPLEXER 5CH 16-TSSOP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG5209FBRUZ, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
