ADG659YCP Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-WQFN Exposed Pad, CSP
- Description: DIFFERENTIAL MUX,4 CHANNEL
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADG659YCP Specifications:
- MfrPart.: ADG659YCP
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: DIFFERENTIAL MUX,4 CHANNEL
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Bag
- Series: ADG659
- PartStatus: Obsolete
- SwitchCircuit: SP4T
- Multiplexer/DemultiplexerCircuit: 4:1
- NumberofCircuits: 2
- On-StateResistance(Max): 75Ohm
- Channel-to-ChannelMatching(ΔRon): 1.3Ohm
- Voltage-SupplySingle(V+): 2V ~ 12V, ±2V ~ 6V
- Voltage-SupplyDual(V±): 2V ~ 12V, ±2V ~ 6V
- SwitchTime(TonToff)(Max): 115ns, 45ns
- -3dbBandwidth: 400MHz
- ChargeInjection: 2pC
- ChannelCapacitance(CS(off)CD(off)): 4pF, 12pF
- Current-Leakage(IS(off))(Max): 200pA
- Crosstalk: -90dB @ 1MHz
- OperatingTemperature: -40°C ~ 85°C
- MountingType: Surface Mount
- Package/Case: 16-WQFN Exposed Pad, CSP
- ADG659YCP Analog Devices (ADI), DIFFERENTIAL MUX,4 CHANNEL, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG659YCP, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
