ADG704BRM ADI SINGLE-ENDED MUX,4 CHANNEL
ADG704BRM Images
ADG704BRM Images
  • Manufacturer: Analog Devices (ADI)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
  • Description: SINGLE-ENDED MUX,4 CHANNEL
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
ADG704BRM Datasheet
ELECTRONIC COMPONENTS, CHOOSE NANHUANG ELECTRONICS
ADG704BRM Specifications:
  • MfrPart.: ADG704BRM-REEL
  • Mfr: Analog Devices Inc.(ADI, AD)
  • Description: SINGLE-ENDED MUX,4 CHANNEL
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Bulk
  • Series: -
  • PartStatus: Obsolete
  • SwitchCircuit: SP4T
  • Multiplexer/DemultiplexerCircuit: 4:1
  • NumberofCircuits: 1
  • On-StateResistance(Max): 4Ohm
  • Channel-to-ChannelMatching(ΔRon): -
  • Voltage-SupplySingle(V+): 1.8V ~ 5V
  • Voltage-SupplyDual(V±): -
  • SwitchTime(TonToff)(Max): 14ns, 6ns (Typ)
  • -3dbBandwidth: 200MHz
  • ChargeInjection: 3pC
  • ChannelCapacitance(CS(off)CD(off)): 9pF, 37pF
  • Current-Leakage(IS(off))(Max): 100pA
  • Crosstalk: -82dB @ 1MHz
  • OperatingTemperature: -40°C ~ 85°C (TA)
  • MountingType: Surface Mount
  • Package/Case: 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
  • ADG704BRM Analog Devices (ADI), SINGLE-ENDED MUX,4 CHANNEL, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG704BRM, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
