ADG774ABRQ Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-SSOP (0.154, 3.90mm Width)
- Description: SINGLE-ENDED QUAD 2:1 MUX
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADG774ABRQ Specifications:
- MfrPart.: ADG774ABRQ-REEL7
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: SINGLE-ENDED QUAD 2:1 MUX
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPDT
- Multiplexer/DemultiplexerCircuit: 2:1
- NumberofCircuits: 4
- On-StateResistance(Max): 3.5Ohm
- Channel-to-ChannelMatching(ΔRon): 150mOhm
- Voltage-SupplySingle(V+): 3V ~ 5V
- Voltage-SupplyDual(V±): -
- SwitchTime(TonToff)(Max): 12ns, 6ns
- -3dbBandwidth: 400MHz
- ChargeInjection: 6pC
- ChannelCapacitance(CS(off)CD(off)): 5pF, 7.5pF
- Current-Leakage(IS(off))(Max): 100pA
- Crosstalk: -70dB @ 10MHz
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-SSOP (0.154, 3.90mm Width)
- ADG774ABRQ Analog Devices (ADI), SINGLE-ENDED QUAD 2:1 MUX, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG774ABRQ, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
