ADG774BRQZ Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-SSOP (0.154, 3.90mm Width)
- Description: SINGLE-ENDED MULTIPLEXER, 4 FUNC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADG774BRQZ Specifications:
- MfrPart.: ADG774BRQZ-REEL7
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: SINGLE-ENDED MULTIPLEXER, 4 FUNC
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Bulk
- Series: -
- PartStatus: Active
- SwitchCircuit: SPDT
- Multiplexer/DemultiplexerCircuit: 2:1
- NumberofCircuits: 4
- On-StateResistance(Max): 2.2Ohm (Typ)
- Channel-to-ChannelMatching(ΔRon): 150mOhm
- Voltage-SupplySingle(V+): 3V ~ 5V
- Voltage-SupplyDual(V±): -
- SwitchTime(TonToff)(Max): 15ns, 8ns
- -3dbBandwidth: 240MHz
- ChargeInjection: 10pC
- ChannelCapacitance(CS(off)CD(off)): 10pF, 20pF
- Current-Leakage(IS(off))(Max): 500pA
- Crosstalk: -75dB @ 10MHz
- OperatingTemperature: -40°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-SSOP (0.154, 3.90mm Width)
- ADG774BRQZ Analog Devices (ADI), SINGLE-ENDED MULTIPLEXER, 4 FUNC, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG774BRQZ, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
