ADG786BCPZ Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 20-WFQFN Exposed Pad, CSP
- Description: IC SWITCH TRIPLE SPDT 20LFCSP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADG786BCPZ Specifications:
- MfrPart.: ADG786BCPZ
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: IC SWITCH TRIPLE SPDT 20LFCSP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tray
- Series: -
- PartStatus: Active
- SwitchCircuit: SPDT
- Multiplexer/DemultiplexerCircuit: 2:1
- NumberofCircuits: 3
- On-StateResistance(Max): 4.5Ohm
- Channel-to-ChannelMatching(ΔRon): -
- Voltage-SupplySingle(V+): 1.8V ~ 5.5V
- Voltage-SupplyDual(V±): ±2.5V
- SwitchTime(TonToff)(Max): 21ns, 10ns (Typ)
- -3dbBandwidth: 160MHz
- ChargeInjection: 5pC
- ChannelCapacitance(CS(off)CD(off)): 11pF
- Current-Leakage(IS(off))(Max): 100pA
- Crosstalk: -80dB @ 1MHz
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Surface Mount
- Package/Case: 20-WFQFN Exposed Pad, CSP
- ADG786BCPZ Analog Devices (ADI), IC SWITCH TRIPLE SPDT 20LFCSP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG786BCPZ, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
