ADG819BRT Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: SOT-23-6
- Description: 2:1 MUX/SPDT SWITCH
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ADG819BRT Specifications:
- MfrPart.: ADG819BRT-REEL7
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: 2:1 MUX/SPDT SWITCH
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPDT
- Multiplexer/DemultiplexerCircuit: 2:1
- NumberofCircuits: 1
- On-StateResistance(Max): 600mOhm
- Channel-to-ChannelMatching(ΔRon): 60mOhm
- Voltage-SupplySingle(V+): 1.8V ~ 5.5V
- Voltage-SupplyDual(V±): -
- SwitchTime(TonToff)(Max): 45ns, 16ns
- -3dbBandwidth: 17MHz
- ChargeInjection: 20pC
- ChannelCapacitance(CS(off)CD(off)): 80pF
- Current-Leakage(IS(off))(Max): 250pA
- Crosstalk: -72dB @ 100kHz
- OperatingTemperature: -40°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: SOT-23-6
- ADG819BRT Analog Devices (ADI), 2:1 MUX/SPDT SWITCH, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ADG819BRT, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
