LT3094EDD Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear Package/Case: 12-WFDFN Exposed Pad
- Description: IC REG LIN NEG ADJ 500MA 12DFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
LT3094EDD Specifications:
- MfrPart.: LT3094EDD#PBF
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: IC REG LIN NEG ADJ 500MA 12DFN
- Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
- Package: Tube
- Series: -
- PartStatus: Active
- OutputConfiguration: Negative
- OutputType: Adjustable
- NumberofRegulators: 1
- Voltage-Input(Max): -2.3V
- Voltage-Output(Min/Fixed): -19.5V
- Voltage-Output(Max): 0V
- VoltageDropout(Max): 0.41V @ 500mA
- Current-Output: 500mA
- Current-Quiescent(Iq): 2.35 mA
- Current-Supply(Max): 23 mA
- PSRR: 108dB ~ 28dB (120Hz ~ 10MHz)
- ControlFeatures: Enable, Power Good, Soft Start
- ProtectionFeatures: Over Current, Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
- OperatingTemperature: -40°C ~ 125°C
- MountingType: Surface Mount
- Package/Case: 12-WFDFN Exposed Pad
- LT3094EDD Analog Devices (ADI), IC REG LIN NEG ADJ 500MA 12DFN, Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
LT3094EDD, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
