MUX24EPZ Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-DIP (0.300, 7.62mm)
- Description: DUAL 4-CH ANALOG MULTIPLEXER
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MUX24EPZ Specifications:
- MfrPart.: MUX24EPZ
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: DUAL 4-CH ANALOG MULTIPLEXER
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tube
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SP4T
- Multiplexer/DemultiplexerCircuit: 4:1
- NumberofCircuits: 2
- On-StateResistance(Max): 300Ohm
- Channel-to-ChannelMatching(ΔRon): 21Ohm
- Voltage-SupplySingle(V+): -
- Voltage-SupplyDual(V±): -
- SwitchTime(TonToff)(Max): 2µs, 400ns
- -3dbBandwidth: -
- ChargeInjection: -
- ChannelCapacitance(CS(off)CD(off)): 2.5pF, 7pF
- Current-Leakage(IS(off))(Max): 1nA
- Crosstalk: -70dB @ 500kHz
- OperatingTemperature: 0°C ~ 70°C (TA)
- MountingType: Through Hole
- Package/Case: 16-DIP (0.300, 7.62mm)
- MUX24EPZ Analog Devices (ADI), DUAL 4-CH ANALOG MULTIPLEXER, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
MUX24EPZ, ADI authentic parts in stock from Analog Devices (ADI) authorized distributors, order today, can ship immediately.
