SW06GP Images
- Manufacturer: Analog Devices (ADI)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-DIP (0.300, 7.62mm)
- Description: QUAD UPST BIFET ANALOG SW
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SW06GP Specifications:
- MfrPart.: SW06GP
- Mfr: Analog Devices Inc.(ADI, AD)
- Description: QUAD UPST BIFET ANALOG SW
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Bulk
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPST - NO/NC
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 4
- On-StateResistance(Max): 150Ohm
- Channel-to-ChannelMatching(ΔRon): 30Ohm
- Voltage-SupplySingle(V+): -
- Voltage-SupplyDual(V±): -
- SwitchTime(TonToff)(Max): 700ns, 500ns
- -3dbBandwidth: -
- ChargeInjection: -
- ChannelCapacitance(CS(off)CD(off)): 7pF, 5.5pF
- Current-Leakage(IS(off))(Max): 60nA
- Crosstalk: -70dB @ 500kHz
- OperatingTemperature: 0°C ~ 85°C
- MountingType: Through Hole
- Package/Case: 16-DIP (0.300, 7.62mm)
- SW06GP Analog Devices (ADI), QUAD UPST BIFET ANALOG SW, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
